Introduction

BugVM is an open source native App building tool. It compiles Java or Kotlin into native machine code and then links with other libraries or frameworks to produce native platform App.

In order to use native UI, bindings are necessary. Currently enough bindings are available for iOS Frameworks. Should the need arise, one can create do-it-yourself bindings to the frameworks or libraries that your App requires.

On macOS, one can build iOS App and macOS console application. The iOS App runs on the simulator, on the device, and can be packaged for the App Store submission.

On 64-bit Ubuntu, console application can be built. This is very useful for the server side scripts or command line tools. The performance gain should be significant.

GitHub Sources

https://github.com/bugvm

Any Question or Feedback? Use GitHub Issue.

Sample iOS App

git clone https://github.com/bugvm/bugvm-ios
cd bugvm-ios
./gradlew sim

Using Gradle Plugin

build.gradle

buildscript {
ext {
    bugVMVersion = "1.2.3"
  }
  repositories {
    mavenCentral()
    maven { url "https://oss.sonatype.org/content/repositories/snapshots" }
  }
  dependencies {
    classpath "com.bugvm:bugvm-gradle:$bugVMVersion"
  }
}

apply plugin: "java"
apply plugin: "bugvm"

repositories {
  mavenCentral()
  maven { url "https://oss.sonatype.org/content/repositories/snapshots" }
}

dependencies {
  compile "com.bugvm:bugvm-rt:$bugVMVersion"
  compile "com.bugvm:bugvm-apple:$bugVMVersion"
}

Gradle Tasks

BugVM plugin defines the following tasks:

launchIPhoneSimulator: Runs your iOS app in the iPhone simulator.
launchIPadSimulator: Runs your iOS app in the iPad simulator.
launchIOSDevice: Runs your iOS app on a connected iOS device.
launchConsole: Runs a console app.
createIPA: Creates .ipa file.

Launch to iPhone Simulator
./gradlew clean build launchIPhoneSimulator
Launch to iPad Simulator
./gradlew clean build launchIPadSimulator
Launch to Device
./gradlew clean build launchIOSDevice
Create IPA for App Store Submission
./gradlew clean build createIPA

Project Properties

The simulator launcher properties can be set by project properties via gradle.properties or -P command line parameter:

bugvm.device.name: Set the device name property. e.g iPhone-7, iPhone-6, iPhone-5s etc
bugvm.sdk.version: Set the sdk version property.

Simulator Device Names on Xcode 8.3

iPhone 5s (iPhone-5s)
iPhone 6 (iPhone-6)
iPhone 6 Plus (iPhone-6-Plus)
iPhone 6s (iPhone-6s)
iPhone 6s Plus (iPhone-6s-Plus)
iPhone 7 (iPhone-7)
iPhone 7 Plus (iPhone-7-Plus)
iPhone SE (iPhone-SE)
iPad Air 2 (iPad-Air-2)
iPad Pro (9.7-inch) (iPad-Pro--9-7-inch-)
iPad Pro (12.9-inch) (iPad-Pro)

To launch on the iPhone-7-Plus simulator:

./gradlew clean build -Pbugvm.device.name=iPhone-7-Plus launchIPhoneSimulator

To launch on the iPad Pro (12.9-inch) simulator:

./gradlew clean build -Pbugvm.device.name=iPad-Pro launchIPadSimulator

The createIPA task will by default include the archs listed in the bugvm.xml file in the archive. Use the bugvm.archs property to specify the archs to include in the archive:

./gradlew -Pbugvm.archs=thumbv7:arm64 createIPA

The bugvmInstall task is very similar to the createIPA task but doesn't archive the folder structure it creates.

To enable bitcode when running createIPA or bugvmInstall, add -Pbugvm.enableBitcode=true:.

./gradlew -Pbugvm.enableBitcode=true -Pbugvm.archs=thumbv7:arm64 createIPA

Building BugVM

You need a Mac running macOS 10.12. Download and install Java SE JDK 8 from Oracle. Make sure $JAVA_HOME is set properly by editing ~/.bash_profile

export JAVA_HOME=$(/usr/libexec/java_home)

Install Xcode 8 from the Mac App Store.

Use xcode-select command line tool to select correct Xcode if there are multiple versions of Xcode.

xcode-select -s /Applications/Xcode.app
or
xcode-select -s /Applications/OtherVersion/Xcode.app

Installing Xcode 8 Command Line Tools

xcode-select --install

You may need to install cmake, pkg-config, openssl if this is first time.

brew install pkg-config
brew install cmake
brew install openssl

Install any other missing components your build systems may complain about.

Clone GitHub repo.

git clone https://github.com/bugvm/bugvm
cd bugvm

The BugVM is built using Gradle Wrapper. If you are new to Gradle, take a look at https://docs.gradle.org/current/userguide/userguide.html. You don't need to install Gradle to use it, very nice.

./gradlew All

Note: It takes a few hours to complete the build process on MacBook Pro.

Building BugVM on Ubuntu 16.04 LTS

apt install git
apt install cmake
apt install g++
apt install libcap-dev
apt install zlib1g-dev
apt install openjdk-8-jdk
apt install g++-multilib
apt install gcc-multilib
apt install libxml2-dev

Install GNU Patch 2.7.3

wget http://ftp.gnu.org/gnu/patch/patch-2.7.3.tar.gz
tar xvf patch-2.7.3.tar.gz
cd patch-2.7.3
./configure
make install

Add JAVA_HOME environment

vi ~/.profile
export JAVA_HOME=/usr/lib/jvm/java-8-openjdk-amd64

Clone GitHub and Build

git clone https://github.com/bugvm/bugvm
cd bugvm
./gradlew All

Download Previous Stable SNAPSHOT

Followings work with Xcode 8 and iOS 10.

Compiler 1.1.19-SNAPSHOT
IDEA plugin 1.1.19-SNAPSHOT
BugVM Studio 1.1.10-SNAPSHOT

Bro

Bro is an API that enables Java code to call directly into native code without using JNI. Let's introduce bro with the most simple example possible:

import com.bugvm.rt.bro.*;
import com.bugvm.rt.bro.annotation.*;

@Library("c")
public class Abs {
    static {
        Bro.bind();
    }
    @Bridge private static native int abs(int i);
    public static void main(String[] args) {
        System.out.println(abs(-100));
    }
}

This example binds the Abs.abs() method to the abs(int) function in the libc system library. The @Library class annotation specifies which dynamic library bro should use to bind the @Bridge annotated methods in the class to (bro will prepend lib and append .so to the specified library name when searching for a matching library). The call to Bro.bind() in the static initializer binds the @Bridge methods when the Abs class is loaded. During binding bro will use dlopen and dlsym to resolve the @Bridge annotated methods. If the @Bridge annotation doesn't specify the symbol to bind to the method name will be used.

Mapping of primitive types

Native integer types (char, int32_t, float) are mapped to Java integer types of the same size:

| Java | Bits | Example C type (depends on compiler and platform) |
|:-------|---:|:----|
| byte   |  8 | char, uint8_t
| short  | 16 | short
| char   | 16 | uint16_t
| int    | 32 | int, int32_t
| long   | 64 | long long, int64_t

Note that unsigned types (e.g. uint32_t) are mapped to the signed Java type of the same size. Native float maps to Java's float and native double maps to Java's double.

Pointers

The simplest way to map a pointer is either pass it in a Java int (assumes 32-bit pointers) or as a Java long annotated with @Pointer. The bro compiler will handle the 64-bit to 32-bit conversions if the target architecture uses 32-bit pointers. Here's an example that calls getenv(char*)to get the value of the HOME environment variable:

import com.bugvm.rt.*;
import com.bugvm.rt.bro.*;
import com.bugvm.rt.bro.annotation.*;

@Library("c")
public class Getenv1 {
    static {
        Bro.bind();
    }
    @Bridge private static native @Pointer long getenv(@Pointer long name);
    public static void main(String[] args) {
        long name = VM.getStringUTFChars("HOME");
        long value = getenv(name);
        System.out.println(VM.newStringUTF(value));
    }
}

This example uses the com.bugvm.rt.VM class to convert zero-terminated C strings into Java String objects. Bro provides special pointer classes for each of the Java primitive types which we can use to make this example look nicer:

import com.bugvm.rt.bro.*;
import com.bugvm.rt.bro.annotation.*;
import com.bugvm.rt.bro.ptr.*;

@Library("c")
public class Getenv2 {
    static {
        Bro.bind();
    }
    @Bridge private static native BytePtr getenv(BytePtr name);
    public static void main(String[] args) {
        System.out.println(getenv(BytePtr.toBytePtrAsciiZ("HOME")).toStringAsciiZ());
    }
}

Structs

C struct types are mapped to Java by extending the bro Struct class. Struct classes must be final. Each member of the C struct is mapped by a getter method and a setter method that must be annotated with the bro @StructMember annotation and given the index of the member in the struct. The names of the getter and setter can follow the Java Beans style convention for Java Beans properties but doesn't have to. Here's a simple example which maps struct timeval and calls gettimeofday():

import com.bugvm.rt.bro.*;
import com.bugvm.rt.bro.annotation.*;
import com.bugvm.rt.bro.ptr.*;

@Library("c")
public class Gettimeofday {

    public static final class Timeval extends Struct {
        @StructMember(0)
        public native int tv_sec();
        @StructMember(0)
        public native void tv_sec(int i);
        @StructMember(1)
        public native int tv_usec();
        @StructMember(1)
        public native void tv_usec(int i);
    }

    static {
        Bro.bind();
    }
    @Bridge private static native int gettimeofday(@ByRef Timeval tp, VoidPtr tzp);
    public static void main(String[] args) {
        Timeval t = new Timeval();
        gettimeofday(t, null);
        System.out.format("Seconds since epoch: %dn", t.tv_sec());
    }
}

The type of the struct member is determined by the return value of the getter and the single argument of the setter method (these have to be identical). The setter must either return no value (i.e. void) or return the Struct type itself. The latter style makes it possible to chain setter calls. The @ByRef and @ByVal annotations can be used to control how a Struct object is returned from a method or passed as a parameter to a method. @ByRef means pass as pointer and is the default. @ByVal means pass by value. The default can be changed to @ByVal for a particular Struct class by annotating the class with @ByVal. Struct classes can contain other Struct objects as members, either by value or by reference (i.e. by pointer). The default is @ByRef with the same possibilities to override the default as for methods. Here's an example of how the Cocoa Touch struct CGRect type is mapped to Java in the BugVM Cocoa Touch bindings: C:

struct CGRect {
    CGPoint origin;
    CGSize size;
};

Java:

import com.bugvm.rt.bro.*;
import com.bugvm.rt.bro.annotation.*;

public final class CGRect extends Struct {
    public CGRect() {}
    public CGRect(float x, float y, float width, float height) {
        origin().x(x).y(y);
        size().width(width).height(height);
    }
    public CGRect(CGPoint origin, CGSize size) {
        origin(origin);
        size(size);
    }

    @StructMember(0)
    public native @ByVal CGPoint origin();
    @StructMember(0)
    public native void origin(@ByVal CGPoint origin);
    @StructMember(1)
    public native @ByVal CGSize size();
    @StructMember(1)
    public native void size(@ByVal CGSize size);
}

Memory handling

When creating an instance of a Struct class bro actually allocates two memory regions. One for the Java object and one for the struct data. The default is to allocate the struct data on the Java heap. This means that the data will be garbage collected when the garbage collector determines that the struct data isn't referenced from any other memory allocated on the garbage collected heap. This won't work for native code that holds on to reference beyond a native function call since the native heap is unknown to the garbage collector. If the native function calls free() on the memory when it's done with it the Java side has to use malloc() to allocate it on the native heap. E.g.:

MyStruct p = Struct.malloc(MyStruct.class);

If the native side holds on to a memory region allocated on the GCed heap care must be taken on the Java side to make sure that memory isn't collected until the native side is done with it. As long as the Java Struct instance is referenced on the Java side the struct data can't be collected. The memory region allocated to hold a struct's data will always be zeroed out no matter if using the Java heap or the native heap.

Native arrays

Here's an example of how to allocate an array of a Struct type MyStruct:

MyStruct l = Struct.allocate(MyStruct.class, 10);

This allocates a contiguous memory region big enough to hold 10 MyStruct instances. The Struct class defines a number of methods that can be used to iterate over these, e.g. next() and previous(). Struct also implements the Iterable interface:

for (MyStruct o : l) {
    ...
    if (l.someMember() == 100) {
        break;
    }
}

Note that the Iterator used when for-looping like this is unbounded so a break is required to finish the loop. The BytePtr class we saw earlier and the other pointer classes in com.bugvm.rt.bro.ptr are in fact Struct classes as well so to allocate a native array of 100 int values one could do:

IntPtr myInts = Struct.allocate(IntPtr.class, 100);

Unbounded native array members

For unbounded native array members one should use one of the pointer classes in the com.bugvm.rt.bro.ptr package combined with the @ByVal annotation: C:

struct PascalString {
    int length;
    char chars[];
};

Java:

public class PascalString extends Struct {
    @StructMember(0) public native int length();
    @StructMember(0) public native void length(int length);
    @StructMember(0) public native @ByVal BytePtr chars();
}

There's no setter for the chars member as that would have required the length to be known at compile time. Setting the individual bytes of chars has to be done through the BytePtr returned by the getter.

Enums

Simple C enums are mapped using Java Enum types which implement the bro ValuedEnum interface. Here's an example: C:

enum {
   NSTextAlignmentLeft      = 0,
   NSTextAlignmentCenter    = 1,
   NSTextAlignmentRight     = 2,
   NSTextAlignmentJustified = 3,
   NSTextAlignmentNatural   = 4,
};

Java:

import com.bugvm.rt.bro.ValuedEnum;

public enum NSTextAlignment implements ValuedEnum {
    Left(0),
    Center(1),
    Right(2),
    Justified(3),
    Natural(4);

    private final long n;

    private NSTextAlignment(long n) { this.n = n; }
    public long value() { return n; }
}

Callback methods

Java:

CallbackTest test = new CallbackTest();

@Callback
public static void callbackMethod(NSData inBuffer) {
    System.out.println("callbackMethod");
}

try {
    Method callbackMethod = this.getClass().getDeclaredMethod("callbackMethod", NSData.class);
    test.nativeSetCallback(new FunctionPtr(callbackMethod));
} catch (NoSuchMethodException e) {
    e.printStackTrace();
}

@Callback
public static void callbackMethod2(int p1, int p2) {
    System.out.println("callbackMethod2 "+p1+"-"+p2);
}

try {
    Method callbackMethod2 = this.getClass().getDeclaredMethod("callbackMethod2", int.class, int.class);
    test.nativeSetCallback2(new FunctionPtr(callbackMethod2));
} catch (NoSuchMethodException e) {
    e.printStackTrace();
}

@Library(Library.INTERNAL)
@NativeClass
public class CallbackTest extends NSObject {

    static { ObjCRuntime.bind(); }

    @Method(selector = "setCallback:")
    public native void nativeSetCallback(FunctionPtr callback);

    @Method(selector = "setCallback2:")
    public native void nativeSetCallback2(FunctionPtr callback);

}

Objective-C

typedef void (*MyCallback)(NSData* data);
typedef void (*MyCallback2)(SInt32 p1, SInt32 p2);
@interface CallbackTest : NSObject {
    MyCallback myCallback;
    MyCallback2 myCallback2;
}
- (void) setCallback:(MyCallback) callback;
- (void) setCallback2:(MyCallback2) callback;
- (void) testCall;
- (void) testCall2;
@end

@implementation CallbackTest
- (void) setCallback:(MyCallback) callback {
    myCallback = callback;
}
- (void) setCallback2:(MyCallback2) callback {
    myCallback2 = callback;
}

- (void) testCall {
    short *byteData= (short*)malloc(1024);
    NSData* data = [[NSData alloc] initWithBytes:byteData length:1024];
    myCallback(data);
    [data getBytes:byteData];
}

- (void) testCall2 {
    myCallback2(123,4567);
}
@end

Support BugVM Project

Introduction

GitHub Sources

Sample iOS App

Using Gradle Plugin

Gradle Tasks

Launch to iPhone Simulator

Launch to iPad Simulator

Launch to Device

Create IPA for App Store Submission

Project Properties

Simulator Device Names on Xcode 8.3

Building BugVM

Building BugVM on Ubuntu 16.04 LTS

Install GNU Patch 2.7.3

Add JAVA_HOME environment

Clone GitHub and Build

Download Previous Stable SNAPSHOT

Bro

Mapping of primitive types

Pointers

Structs

Memory handling

Native arrays

Unbounded native array members

Enums

Callback methods
